Body: Ductile iron EN-GJS-400-15 (GGG40)
Disc: Ductile iron EN-GJS-400-15 (GGG40) nickel-plated or Stainless steel 316
Seat: Heat EPDM or EPDM ACS
Connection: Flanged PN16
Working pressure: 16 bar
Maximum Working temperature: +130°C (+150°C peak)
Minimum Working temperature: -15°C (- 30°C peak)
Working temperature for ACS: +110°C (+130°C peak) / +4°C (-20°C peak)
Operation: Gearbox with handwheel and ISO top flange for electric actuator
connection
